Key Highlights

• 2200 ANSI Lumens Ultra Brightness – Crystal-clear visuals even in bright rooms using OSRAM LED & 3RGB DLP technology

• Full HD Native + 4K Support – Native 1920×1080 resolution with 4K decoding

• Autofocus + Auto Keystone – Electric motor focus with automatic 4-point digital keystone correction

• Premium Harman Kardon Sound – Dual 10W speakers with Dolby sound effects

• Android 11 Smart Projector – Built-in apps like YouTube, Netflix & Prime Video

• Dual-Band WiFi + Bluetooth 5.0 – Wireless casting, screen mirroring, speaker & gamepad support

• Huge Screen Projection – 30" to 300" display size, 1–6 meter throw distance

• 50,000 Hours OSRAM LED Life – Ultra long-lasting light source

• Optional Built-in 30,000mAh Battery – Up to 3 hours playback in standard mode

• Portable & Powerful – Ideal for home theater, office, classroom & outdoor use

 Display & Optics

• Display Technology: 1-chip DLP, TI 0.47” DMD, 3RGB LED

• Brightness: 2200 ANSI Lumens

• Resolution: 1920×1080 Native, Supports 4K

• Contrast Ratio: 50,000:1 (FOFO)

• Uniformity: >95%

• Light Source: OSRAM LED (>50,000 hours)

• Zoom: 110%

• Throw Ratio: 0.91 – 2.5

• Projection Size: 30” – 300”

• Projection Distance: 1 – 6 meters

• Aspect Ratio: 4:3 / 16:9 / 16:10

• 3D Support: Yes (DLP-Link)

 Focus & Projection Modes

• Focus Mode: Auto Focus (Electric Motor)

• Keystone Correction: Automatic Digital 4-Point

• Projection Modes: Front / Rear / Ceiling Mount

Audio System

• Speaker: 10W × 2 Harman Kardon Stereo

• Sound Effects: Dolby Audio Supported

 System & Performance

• CPU: 64-bit Quad-Core Cortex-A53

• GPU: Mali-G52

• RAM: 2GB DDR3

• Storage: 32GB eMMC

• OS: Android 11.0

• 4K Decode: H.265 / AVS2 / 4K@30Hz

Wireless & Connectivity

• WiFi: Dual Band 2.4G / 5G

• Bluetooth: BT 5.0

• Wireless Cast: WiFi Screen Mirroring & Hotspot Cast

• Remote: IR + 2.4G Wireless Remote Support

Ports & Interfaces

• HDMI: HDMI 2.0

• USB: 2 × USB 2.0 Host

• TF Card: Supported

• AV Input: Yes

• Ethernet: Yes

• Audio Out: 3.5mm Headphone Jack

• DC Input: 19V 2.1A

 Power & Battery

• Power Consumption: < 72W

• Power Supply: AC 100–240V, 50/60Hz

• Battery (Optional): 30,000mAh Lithium

  • Charging Time: ~2 Hours

  • Playback: 2.5 hrs (High Mode), 3 hrs (Standard Mode)

 Build & Physical Specs

• Material: ABS Plastic + Metal Electroplating

• Product Size: 198 × 187 × 157 mm

• Net Weight: 2383 g

Environment

• Working Temperature: 5°C – 40°C

• Working Humidity: 20% – 80%

Packaging Details

• Package Weight (1 Unit): 3.32 Kg

• Package Weight (4 Units): 14.78 Kg

• Carton Size (4 Units): 485 × 245 × 465 mm

Warranty

• 3 Years On-Site Warranty

• Light Source Warranty: 3 Years or 12,000 Hours (Whichever Earlier)
